Programming a 1997 Finn Power Turret Punch Press requires a deep understanding of the machine's mechanical components, CNC control system, tooling, and software environment. This comprehensive guide will walk you through the fundamental steps to program and operate this classic CNC turret punch press effectively. We will cover machine setup, tool library configuration, programming basics, optimization techniques, troubleshooting tips, and provide visual aids for better comprehension.
The 1997 Finn Power Turret Punch Press is a robust CNC machine designed for sheet metal punching and shearing. It features:
- A 20-station turret capable of holding various tool holders.
- Hydraulic punching cylinder with adjustable stroke length.
- Integrated right-angle shear for cutting parts from sheets.
- Control systems typically based on Siemens Sinumerik 840D or Fanuc 16P CNC.
- Capable of punching up to 8 mm thick steel sheets.
- Automatic tool indexing and programmable punch speeds.
- Workpiece positioning via CNC-controlled X, Y, T, and C axes.
The machine moves the sheet metal precisely under the turret, which punches holes, shapes, or forms the metal according to programmed commands. This combination of hydraulic power and CNC precision makes the Finn Power turret punch press a versatile and reliable machine in metal fabrication shops.
- Turret: Holds up to 20 tools, including punches, dies, and forming tools.
- Ram: The hydraulic cylinder that drives the punch downward.
- Work Table: Usually a brush or ball table that supports the sheet metal and allows smooth movement.
- Clamps: Secure the sheet metal during punching to prevent shifting.
- Shear Unit: Integrated right-angle shear for cutting parts from the sheet.
- Control Panel: CNC interface for programming and operating the machine.
Before programming, ensure the machine is correctly installed and maintained:
- Follow hoisting and handling instructions carefully.
- Confirm hydraulic and pneumatic systems are operational.
- Verify the turret is loaded with the correct tool holders and tools.
- Make sure the work table is clean and free of debris.
- Operators must be trained and familiar with safety protocols.
- Always wear appropriate personal protective equipment (PPE).
Programming begins with building a tool library in the CNC control software (e.g., NC Express):
- Define each tool type: round, square, rectangular, obround, shear, special forming tools, etc.
- Input tool dimensions, punch and die clearances, stripper height, punch depth, and ram speed.
- Assign tools to specific turret stations based on the physical layout.
- Consider tool priorities for nibbling or punching sequences.
- Lock tools in stations if they will not be changed frequently to prevent accidental changes.
A well-organized tool library is the foundation of efficient programming. It helps the CNC system know exactly which tool to use for each operation and ensures consistent quality.
The turret has 20 stations, with holes sized for 110 mm or 135 mm tool holders. Multi-tool stations can increase tool capacity:
- Plan tool placement for efficient punching flow.
- Use multi-tool stations (e.g., MT24-8, MT8-24) to maximize tool availability.
- Ensure forming stations are equipped if part forming is required.
- Avoid placing frequently used tools too close to clamps or protection zones.
Proper turret layout reduces tool changes and travel time, increasing productivity and reducing wear.
Programming can be done via the CNC control panel or offline software:
- Input coordinates for each punch or cut relative to the sheet origin.
- Define punch sequences, including single strokes, nibbling, or cutting.
- Program tool changes and turret indexing commands.
- Set punch stroke length according to material thickness using fixed offset and multiplication factors.
- Include clamp positioning commands to secure the sheet during punching.
- Use program optimization features to minimize turret movement and tool changes.
The programming language is usually a form of G-code or proprietary commands tailored for turret punching. Understanding the syntax and commands is essential for accurate programming.
- Transfer the program to the CNC control via RS232, Ethernet, or USB depending on machine interface.
- Perform a dry run or simulation to verify tool paths and sequences.
- Load the sheet metal onto the work table and secure it with clamps.
- Start the program and monitor the operation for any errors or misfeeds.
- Adjust punch speed and stroke if needed for noise reduction or difficult shapes.
Efficient programming involves minimizing turret movement and tool changes. Consider:
- Grouping punches by tool to reduce indexing.
- Sequencing punches to avoid unnecessary travel.
- Using multi-hit or nibbling techniques for complex shapes.
- Programming partial strokes for delicate materials to prevent deformation.
These optimizations reduce cycle time and improve tooling life.
The Finn Power turret punch press supports forming tools for embossing, louvers, and countersinks:
- Include forming tool commands in the program.
- Adjust punch stroke and speed to accommodate material deformation.
- Program tool change and turret indexing accordingly.
Forming tools expand the machine's capabilities beyond simple punching.
The integrated right-angle shear allows cutting parts from the sheet:
- Program shear commands after punching is complete.
- Position the sheet precisely before cutting.
- Use multiple shear strokes for complex shapes.
Combining punching and shearing in one program streamlines production.
- Rapid tool wear due to incorrect punch-die clearance or misalignment.
- Material feeding problems causing incomplete or misplaced punches.
- Alignment issues between turret and sheet causing poor quality holes.
- Control system faults such as lost parameters due to battery failure.
- Punch vibration causing system restarts or air pressure alarms.
- Regularly check and adjust punch and die clearances.
- Maintain lubrication and clean tooling surfaces.
- Inspect and calibrate turret alignment periodically.
- Backup CNC and PLC parameters; replace backup batteries as needed.
- Inspect wiring and signal lines to prevent vibration-induced faults.
- Daily cleaning of the work table and tool holders.
- Weekly lubrication of turret and ram components.
- Monthly inspection of hydraulic fluid levels and filters.
- Annual calibration of CNC axes and turret indexing.
- Regular software updates and backup of CNC programs.
Proper maintenance extends machine life and prevents unexpected downtime.
Programming the 1997 Finn Power Turret Punch Press involves a thorough understanding of its mechanical setup, CNC control system, and tooling configuration. By carefully creating a detailed tool library, planning turret layouts, and programming precise punch sequences, operators can maximize the machine's productivity and part quality. Advanced programming techniques such as optimizing punch sequences, using forming tools, and integrating shearing operations further enhance efficiency. Regular maintenance and troubleshooting ensure longevity and reliable operation of this classic turret punch press.
With the right knowledge and preparation, the 1997 Finn Power Turret Punch Press remains a powerful asset in any sheet metal fabrication environment.
To create a tool library, define each tool's shape, size, punch and die clearances, and assign it to a turret station using the CNC control software like NC Express. Lock tools in place if they will not be frequently changed to avoid errors. Accurate tool data ensures consistent punching quality.
The machine can punch steel sheets up to 8 mm thick and shear materials up to 5 mm depending on the material type and tooling. Thicker materials may require slower punch speeds or specialized tooling.
Use the machine parameters ‘Fixed Offset' and ‘Multiplication Factor' to calculate stroke length. Multiply the material thickness by the factor and add the offset to set the correct punch depth in the CNC program. This ensures clean punches without excessive ram travel.
Replace the backup battery on the control unit and reload the machine parameters and PLC program from backup media. If no backup exists, seek help from the manufacturer or user forums for parameter files. Regular backups prevent data loss.
Ensure correct punch and die clearance, maintain proper lubrication, regularly calibrate tool alignment, and avoid punching near clamps or protection zones. Using multi-tool stations can also reduce wear by distributing tool usage evenly.
